Vibration Testers

Vibration Testers - For Accurate and Precise Machinery Testing

Are you a mechanical engineer, equipment operator or maintenance technician looking for a reliable and accurate way of testing the vibration levels of your machinery? Look no further than our Vibration Testers!

Our Vibration Testers are designed to provide precise vibration measurements of industrial machines, including motors, fans and pumps. This is critical for maintaining the optimal performance of any equipment, as well as ensuring the safety of personnel operating the machinery.

Our Vibration Testers come equipped with a high-performance accelerometer that detects vibration levels from even the smallest deviations. Its compact and lightweight design allows for easy hand-held operation, providing accurate readings with minimal effort.

Our Vibration Testers provides a range of functions for the utmost convenience of users. They include:

- Choosing to display measurements in velocity, displacement, acceleration or overall vibration value.

- Setting alarm levels for vibration and RMS with red and green LED indicators.

- Providing an auto power-off function to conserve battery life.

- Allowing for easy transfer of data to a computer.

Our Vibration Testers are a reliable and cost-effective solution for performing regularly scheduled machinery maintenance and troubleshooting. The readings produced by our testers enable engineers to determine the cause and location of any issues within machinery. This knowledge helps to prevent breakdowns, minimize downtime, and save time and money.

Our Vibration Testers are also easy to use, even for those whose profession is not vibration testing. Whether you are an experienced technician or a newly trained operator, our testers are user-friendly and designed to be operated with ease.

We understand the importance of quality and strive to provide our customers with the highest quality products available. Our Vibration Testers are CE certified and manufactured with the highest quality materials. Our production team is dedicated to ensuring that each tester meets our strict quality control standards, so you can have the confidence that the product you receive meets your expectations.

We provide our testers to merchants worldwide and are committed to providing the highest level of customer service possible. We are always available to answer questions, provide support, and ensure our customers are satisfied with their purchase.

In conclusion, our Vibration Testers provide an accurate, reliable and cost-effective solution for detecting vibration levels in machinery. With its various functions, anyone who has a basic knowledge of machinery can use these testers easily. We take great pride in the quality of our products and are committed to providing the highest level of customer service. Choose our Vibration Testers and experience the accuracy and reliability you can trust. Order your testers today and experience the difference.

VIB^®05 Vibration testers

The 3-in-1 machine condition monitoring

Vibration·Bearing Condition·Temperature

Vibration monitoring with VIB05

Vibration monitoring is a cost-effective predictive maintenance strategy. Changes in vibration levels are usually only changes in operating conditions, but in most cases, vibration measurements can detect problems long before the machine is damaged. Periodic vibration measurements of fans, motors, pumps, compressors and other rotating industrial machinery help prevent premature replacement of mechanical parts and minimize downtime.

The VIB05 Vibration testers portable Vibration and Temperature Meter Kit has been designed for use as both an entry level and also a comprehensive vibration/temperature monitoring instrument for maintenance engineers across all types of industry. The kit consists of the compact vibration meter with a combined non-contact temperature measuring sensor airded by a locator beam, a hand held probe, a magnetic mount for more permanent installations, a protective carrying case, an instruction manual and battery chargers for both mains and in-car use. The Vibration testers is microprocessor based and by selection of the controls can be easily set up to monitor acceleration (g) levels, velocity (mm/sec), displacement (µm), bearing condition (BG or BV) and temperature (°C or °F). A display hold function is also included. The unit, which conforms to ISO 2954 and ISO 10816-3 also has an automatic alarm check for bearing condition. Operating from an internal re-chargeable Lithium battery, the meter offers 48 hours continuous operation. From flat, the unit can be recharged in 3 hours using either the mains or in-car charger supplied with the kit. Because of its compact size, ease of use and battery operation, the VIB05 allows engineers to monitor vibration and temperature levels on important machinery anywhere around the factory

The VIB05 Vibration testers can be used to effectively monitor vibration levels in most types of rotating machinery, such as electric motors, fans, and pumps, in a diversity of industrial environments.

3 Measurements

Machine Vibration Measures

Velocity in mm/s RMS; Acceleration in g RMS; Displacement in um Peak-Peak

Vibration Evaluation: According to ISO10816-3.

Bearing Condition Measures

Bg - Hi Frequency Acceleration in g RMS;Bv - Hi Frequency Velocity in mm/s RMS.

Bearing Status Check: By using rules of thumb

Temperature Measure

Non-contact Infrared Sensor,Target and Environment in °C or °F,Red Laser Pointer.

VIB05 Specifications

Display: Monochromatic LCD, 128x64 pixial

Sensor: IEPE Accelerometer, 100mv/g, Integral 80 cm cable, BNC connector

Vibration:

Acceleration: 0-20 g Peak Frequency 10-12kHz

Velocity: 0-200mm/s RMS Frequency 10Hz-1kHz

Displacement: 0-2000 μm Peak-Peak Freq. 10Hz-1kHz

Bearing Status:

Bg: 0-20 g RMS Freq. Range 1kHz-12 kHz

Bv: 0-200 mm/s RMS Freq. Range 1kHz-12 kHz

Accuracy: < +/-5%

Alarm Indication:

Vibration Evaluation for velocity measure: ISO10816-3

Bearing Status check for BG and BV: Rule-of-thumb

Temperature:

IR Sensor temperature range: -20 °C to 120°C or -5°F to +250°F

Accuracy: ±2°C; Resolution: 1°C;

Laser guide : Red, <1mW. IEC 60825-1 compliant

Distance to surface D:S = 8:1; Recommend distance range: < 20 cm

Power & Charger:

Lithium rechargeable battery, 3.6V 1700 mAh,

Recharge time 3 hours ; Operating time >50 hours continuous

Mains charger: AC 100-240 V, 50/60 Hz input; 4.2 V DC 600 mA output

In-car charger: DC 12-24 V input; 4.2 V DC 600 mA output。

Environment:

Operation temperature: -10°C to +50°C; Storage temperature: -20°C to +60°C

Enclosure: IP64 - Dust-tight and splash-resistant

Electromagnetic compatibility certificate: 2004/108/EC

Dimensions:115 x 75 x 25mm（LxWxT）

Weight incl. battery:230g

VIB05 Complete Kit
