Wireless Vibration Vibrometer
KMWIS Wireless Vibration Sensor is a portable Single Axis Piezo-electric Wireless Accelerometer which operates on Android Mobile / Tab.
Features
KMWIS Wireless Vibration Sensor is a portable Single Axis Piezo-electric Wireless Accelerometer which operates on Android Mobile / Tab. KMWIS Wireless Vibration Sensor is a wireless ultra-low noise accelerometer with 10 kHz bandwidth that exceeds the characteristics above all of most conventional accelerometers.
Features
Multiple parameter collection
● Support for multiple signal types: ACC, Vel, Disp, Env, BC, FFT, Time waveform
Wireless Signal acquistion
● Wireless communication range up to 50 meters (depending on field condition)
Ultra low power consumption
● 10 hours of operation on a single charge
Quick installation
● Built-in magnetic suction base
Premium protection
● IP67 industrial grade protection with Ex Proof certification
Easy to charging
● Standard USB connector helping you charging at any time
Functions
Vibration Meter
Vibration Analysis
Time Waveform Analysis
FFT Spectrum Analysis
Complete Kit
Specifications
|
Metrology |
|
|
Sampling frequency |
Max 25.6 Khz |
|
Sensing element |
Piezoelectric / Annual shear mode |
|
Full scale |
50 g |
|
Signal-to-Noise ratio |
> 80 dB |
|
Frequency response |
± 3dB 0.4 Hz - 10 KHz |
|
Accuracy |
+ / - 5% @ 150 Hz, 1 g |
|
Signal |
RMS, Peak, peak to peak, Bearing status value |
|
FFT resolution |
6400 lines |
|
Waveform type |
Acceleration, Velocity, Displacement, Envelope |
|
Bearings condition |
BC<1, well; 1 |
|
Measurement duration |
3s typical (affected by distance & communication) |
|
Frequency range |
Vel & Disp (10 ~ 1,000 Hz); Acc (2 ~ 5000Hz) |
|
Vibration setup |
Automatic definition of the measurements based on the machine class |
|
Physical |
|
|
Dimensions |
41.8 x 69.4 mm |
|
Weight |
228 g |
|
Mounting |
M6 threaded hole |
|
LED indicator |
Red, Green, Blue |
|
Environmental |
|
|
Operating temperature |
-30℃ ~ 70℃ |
|
Protection |
IP67 |
|
Explosion proof |
Exib IIC T4 Ga |
|
ISO standard |
compliance ISO 10816-3 |
|
Humidity |
0% to 95% relative humidity (RH) |
|
Battery |
|
|
Type |
Li-ion |
|
Operating lifetime |
more than 10 hours (Continuously) |
|
Charging time |
1 - 2 hours |
|
Capacity |
750 mAh |
|
Rechargable |
with marching charger |
|
Communication |
|
|
Wireless protocol |
Wifi point to point |
|
Wireless range |
Upto 50 meters depending on the environment |
|
Standard mobile system compatibility |
Android |
